Electrical system |
controller |
Inbor controller |
|||
|
battery |
60V*120AH |
||||
|
electrical machinery |
3.5kw |
||||
|
Charger |
Vehicle mounted intelligent charger |
||||
|
charging time |
6-8 hours |
||||
|
Charging input voltage |
110v-220V |
||||
|
Technical parameters |
Speed |
27-35km/h |
|||
|
gradeability |
>20% |
braking distance |
≤5.0m |
||
|
minimum turning radius |
6750mm |
Ground clearance |
235mm |
||
|
size |
4200*1250*1850mm |
Driving range |
100km |
||
|
wheelbase |
3150mm |
Allowable passenger |
6 |
||
|
Track width (front and rear) |
990/1000mm |
（kg）Vehicle equipment mass (kg) |
720kg |
||
|
Body system |
seat |
High rebound integral leather waterproof seat |
|||
|
car body |
Steel frame+injection molded shell/ABS engineering plastic molded parts |
||||
|
instrument |
Instrument display (including voltage) |
||||
|
rearview mirror |
Manual exterior rearview mirror |
||||
|
Lights and signals |
LED combination front light, turn signal, combination rear tail light, brake light, electric horn |
||||
|
switch |
tart switch, light, forward/backward gear switch |
||||
|
Steering wheel |
Polyurethane foam steering wheel |
||||
|
Chassis system |
powertrain |
Continuously variable speed system |
|||
|
Steering |
Rack and pinion steering system |
||||
|
suspension |
Front axle threaded spring suspension, rear suspension with multiple leaf springs, and cylindrical hydraulic shock absorbers |
||||
|
brake system |
Four wheel hydraulic assisted braking, drum type wheel brake, and mechanical parking brake |
||||
|
wheel |
Vacuum Meridian High Quality Automotive Special Tyres (205/50-10) |
||||
|
Customized vehicle model: 2-seater, 4-seater, 6-seater, 8-seater, 10-seater |
|||||
|
Motor selection: 3.5kw, 4kw, 5kw, 7.5kw, etc |
|||||
|
Optional: sunshades, rain curtains, etc |
|||||
